Características detalladas del producto:
CPU. . Supports Intel® Core™ Ultra Processors (Series 2), LGA1851*. Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**. * Refer to https://www.asus.com/support/download-center/ for CPU support list.. ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.. . Chipset. . Intel® B860 Chipset. . Memory. . 2 x DIMM slots, max. 128GB, DDR5. Supports up to 8800+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*. Dual channel memory architecture. DIMM Fit. Supports Intel® Extreme Memory Profile (XMP) memory module. ASUS Enhanced Memory Profile III(AEMPIII). * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market.. ** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.. . Graphics. . 1 x DisplayPort**. 1 x HDMI™ port*** . * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.. ** Supports max. 4K@60Hz as specified in DisplayPort 1.4.. *** Supports 4K@60Hz as specified in HDMI 2.1.. **** VGA resolution support depends on processors' or graphic cards' resolution.. . Expansion Slots. . Intel® Core™ Ultra Processors (Series 2). 1 x PCIe 4.0 x16 slot. Intel® B860 Chipset. 2 x PCIe 4.0 x1 slots. - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.. . Storage. . Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*. Intel® Core™ Ultra Processors (Series 2) *. M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode). Intel® B860 Chipset. M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode). 4 x SATA 6Gb/s ports. * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.. . Ethernet. . 1 x Realtek 2.5Gb Ethernet. ASUS LANGuard. . USB. . Rear USB (Total 6 ports). 1 x USB 10Gbps port (1 x Type-A). 2 x USB 5Gbps ports (2 x Type-A). 3 x USB 2.0 ports (3 x Type-A)**. Front USB (Total 7 ports). 1 x USB 5Gbps connector (supports USB Type-C®). 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports. 2 x USB 2.0 headers support 4 additional USB 2.0 ports**. * USB Type-C® power delivery output: max. 5V/3A.. ** USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.. . Audio. . Realtek 7.1 Surround Sound High Definition Audio CODEC*. - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking. - Supports up to 24-Bit/192 kHz playback. Audio Features. - Audio Shielding. - Premium audio capacitors. - Dedicated audio PCB layers. * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.. . Back Panel I/O Ports. . 1 x USB 10Gbps port (1 x Type-A). 2 x USB 5Gbps ports (2 x Type-A). 3 x USB 2.0 ports (3 x Type-A). 1 x DisplayPort. 1 x HDMITM port. 1 x Realtek 2.5Gb Ethernet port. 3 x Audio jacks. 1 x PS/2 Keyboard/Mouse combo port. . Internal I/O Connectors. . Fan and Cooling Related. 1 x 4-pin CPU Fan header. 2 x 4-pin Chassis Fan headers. Power Related. 1 x 24-pin Main Power connector. 1 x 8-pin +12V CPU Power connector. Storage Related. 2 x M.2 slots (Key M). 4 x SATA 6Gb/s ports. USB. 1 x USB 5Gbps connector (supports USB Type-C® ). 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports. 2 x USB 2.0 headers support 4 additional USB 2.0 ports. Miscellaneous. 2 x Addressable Gen2 headers. 1 x Aura RGB header. 1 x Clear CMOS header. 1 x COM Port header. 1 x Front Panel Audio header (F_AUDIO). 1 x S/PDIF Out header. 1 x SPI TPM header (14-1 pin). 1 x 10-1 pin Front Panel System header. . BIOS. . 256(128+128) Mb Flash ROM, UEFI AMI BIOS. . Manageability. . WOL by PME, PXE. . Form Factor. . micro-ATX Form Factor. 9.6 inch x 8.75 inch (24.4cm x 22.2cm)
Características técnicas del producto:
- Chipset: Intel B860
- Formato: Micro ATX
- Hdmi: Si
- Imagen Salida: Graficos en CPU, HDMI, Displayport
- Memoria Maxima: 128GB
- Microprocesador Integrado: No
- Multi-Grafica: No
- N Bancos De Memoria: 2
- N Conexiones SATA: 4
- N USB 2.0: 3 Traseros, 4 Internos
- N USB 3.2 Gen1: 2 Traseros, 2 Interno, 1 Interno Tipo C
- N USB 3.2 Gen2: 1 Trasero
- Raid: Si
- SATA 6Gb/S: 4
- Socket: Intel LGA 1851
- Tecnologia De Memoria: DDR5
- Tipo De Raid: 0,1,5,10
- USB 3.0: Si
- USB3.1 Interno: Si
